T3 RGB Touch Panel Controller | 3CH 4A 12–24V LED Wall Control

Overview

The T3 is a wall-mounted RGB touch panel controller designed for direct control of RGB LED strips through its built-in 3-channel constant voltage output. With 4A per channel and a 12–24V DC input range, it delivers smooth color mixing, brightness dimming and saturation adjustment. The T3 also supports 2.4G RF wireless communication, allowing synchronization with external RF RGB receivers for multi-zone control. Its glass touch interface and sleek design make it ideal for modern residential and commercial lighting.

Key Features

• 3-channel constant voltage RGB output (3×4A)
• Input voltage range: 12–24V DC
• Wall-mounted capacitive touch panel
• Touch color wheel for smooth RGB selection
• Brightness dimming and saturation adjustment
• Built-in 2.4G RF transmitter for wireless control
• Can control RGB strips directly or via RF receivers
• Memory function restores last settings on power-up
• Modern glass panel for a clean, premium finish

Technical Notes

• The T3 can operate as a standalone controller via its 3CH output.
• It can also wirelessly control multiple RF RGB receivers.
• Supports PWM dimming for flicker-free performance.
• Designed for indoor installations in dry environments.
• Standard 86-type box or EU wall box mounting.

Color & Brightness Adjustment

• Touch wheel: Select RGB colors smoothly
• Brightness keys: 0–100% adjustment
• Saturation keys: Adjust color intensity
• Mode keys: Optional RGB dynamic effects (depending on version)

Applications

• RGB LED strip lighting
• Residential ambient and decorative lighting
• Hotels, bars, lounges and restaurants
• Showrooms and retail environments
• Cove and indirect RGB lighting installations
• Architectural lighting featuring color control

Technical Specifications

Parameter	Specification
Model	T3 RGB Touch Panel Controller
Output Channels	3 channels × 4A (RGB)
Input Voltage	12–24V DC
Output Type	Constant voltage PWM
Wireless Protocol	2.4G RF (RGB receivers)
Max Output Power	Up to 96W @ 24V / 48W @ 12V per channel
Control Type	Touch wheel + buttons
Mounting	Wall-mounted (86-type / EU box)
Operating Environment	Indoor, dry locations
