V1-T Push-Dim LED Controller | 1CH 8A 5–36V Constant Voltage Dimmer

Overview

The V1-T is a single-channel constant voltage LED dimming controller designed for 5–36V DC LED strips and low-voltage lighting systems. It features Push-Dim control, allowing ON/OFF and brightness adjustment using a standard momentary wall switch. With an 8A output capacity and smooth PWM dimming, the V1-T is ideal for residential, commercial and furniture lighting applications.

Key Features

• 1-channel constant voltage LED dimmer
• Supports 5–36V DC LED systems
• High output current: 8A max
• Push-Dim control (momentary switch)
• Smooth 0–100% PWM dimming
• Memory function restores last brightness level
• Compact and easy to install
• Ideal for LED strips, bars and low-voltage luminaires

Technical Notes

• Push-Dim allows brightness adjustment and ON/OFF control with a standard wall switch.
• Short press = ON/OFF; long press = dimming adjustment.
• Designed for 12V, 24V and 36V LED strip systems within the 5–36V range.
• Ensure an appropriate DC power supply matching LED voltage.
• Do not exceed 8A output current.

Wiring & Installation Notes

• Connect 5–36V DC power to the input terminals (observe polarity).
• Connect LED strip or load to the output terminals.
• Connect a momentary switch to the Push-Dim input.
• Install in a dry indoor location (IP20).
• Suitable for junction boxes, cabinets or aluminum profiles.

Applications

• Single-color LED strip dimming
• Furniture and cabinet lighting
• Residential and commercial lighting
• Linear LED profiles
• Under-shelf lighting
• Any low-voltage LED system requiring dimming
